Place of Origin : Security Cameras
Brand Name : Mobile Cameras
Model Number : DR-MD560036
Certification : CE, FCC
Price : USD42
Packaging Details : 1pc per polybag, color box
Delivery Time : 10 days
Payment Terms : TT, Western Union, Paypal
Supply Ability : 50000pcs per month
Price term : EXW
Type : Analog Camera
Style : Dome Camera
Sensor : CCD
Technology : Infrared
Special Features : Waterproof / Weatherproof
MOQ : 1pc
Port : Yantian Shenzhen
China Facorty Best Offer Bus Surveillance IR Day/Night Mini Metal CCTV Dome Camera DR-MD560036
Features:
◆Bus Mini Metal Dome Camera
◆IP67 Waterproof & Vandalproof, resistant to water burst cleaning process
◆Compact function for Shutter/Auto; BLC/Auto, AGC/Auto
◆Easy Installation Dome Mechanical Design
◆Fixed lens 2.8/3.6/6.0mm
◆10 leds(MD4R for Options)
◆MD5/MD5R: D76x55.8(mm)


| Model | DR-MD560036 |
| Pick up Device | 1/3” Sony 639CCD + NextChip 2040 DSP |
| TV System | PAL/ NTSC |
| Picture Elements | 752Hx582V |
| Horizontal Resolution | 600TVL |
| Sensitivity | 0 Lux at F1.2 (LED On) |
| Scanning System | 625TVL/2:1 Interlace |
| Synchronization | Internal |
| S/N Ratio | More Than 50 dB, (AGC Off) |
| IR LED | 10 LEDs with 850nm |
| Infrared range | 3 Meter |
| Auto Gain Control | Auto |
| White Balance | Auto |
| Electronic Shutter | Auto |
| Back Light Compensation | Auto |
| Mirror | Optional |
| Video Output | 1 Vp-p, 75ΩComposite |
| Audio | N/A |
| Gamma Ratio | 0.45 |
| Lens | Standard f3.6mm Fixed Iris Lens |
| Lens Mount | M12XP0.5mm Thread |
| Horizontal Angle of View | +/-95 degree |
| Pan Adjusting | +/-180 Degree |
| Tilt Adjusting | 0-62 Degree |
| Power Supply | 12V DC ±10% |
| Power Consumption | 210mA |
| Dimensions (ø X H) | 77 x 60.3 mm |
| Net Weight | 200 g |
| Weatherproof | IP67 |
| Operating Temperature | -10°C to +50°C |
